Blue Sea e-Series Single Circuit ON-OFF Battery Switch

Blue Sea Systems e-Series Single Circuit ON-OFF Switch

Features:

• Ignition protected - safe for installation aboard gasoline powered boats
• Case design allows surface or rear panel mounting
• Meets American Boat and Yacht Council (ABYC) requirements for battery switches
• Cranking Rating: 10 sec. 2,000 Amps
• Intermittent Rating: 5 min. 600 Amps
• Continuous Rating 350 Amps
• Maximum Voltage Rating 48 Volts DC
• Terminal Stud Size 3/8"-16 (M10)
• Terminal Stud Torque 140 in-lb (15.82 Nm) max.
• Mounting Holes Accept 1/4" (M6) Screw
• Cable Size to Meet Ratings 4/0 AWG (95mm²)
• Cable Clearance For 4/0 AWG Cables 1.10" (27.9mm)
• Weight 0.95lb (0.43)
• UL Listed - UL 1107 electric power switches
• Meets American Boat and Yacht Council (ABYC) requirements
• Meets UL 1500 and SAE J1171 external ignition protection requirements
• Single Circuit ON/OFF
